Built for serious commercial hauling, the F5 raises the bar to 20,000 lb GVWR with a low-profile dual tandem configuration. Fifteen length options from 20 to 44 feet accommodate virtually any heavy equipment hauling scenario with reinforced structural steel throughout.
Full 102″ wide deck in a compact bumper pull package
20,000 lb GVWR for maximum payload capacity
Nine length options from 20′ to 40′
Built for professional commercial transport operations
| Specification | Detail |
|---|---|
| Model | C030 |
| MSRP | $18,897.20 |
| Frame | 10" x 15 lb I-Beam Frame & Neck w/ Rub Rail |
| Hitch | 2 5/16" 25K Round Gooseneck Coupler |
| Axles | Axle, (2) 10K Electric, Torsion (95-72) 0 Deg |
| Back | 4’ Dove w/ Slide-in Ramps |
| Color | Midnight Black (PBS9-00005) |
| Tire | 5 - 215/75R17.5 LRH Radial 16ply Tires |
| Cross-member | Crossmembers, 3" Channel on 16" Centers |
| Jack | Jack, (2) 12K Spring Loaded |
| Fenders | Drive Over Fenders (Diamond Plate Fenders) |
| Floor | Treated Pine Wood Floor |
