Home › Trailers › Carhauler Trailers › C5
At 14,000 lb GVWR, the C5 handles everything from performance cars to landscaping equipment to small skid steers. Eight length configurations give dealers and end users maximum flexibility to match the trailer to specific payload requirements.
14,000 lb GVWR handles a wide range of loads
83″ wide deck in eight length configurations
From 12′ compact to 26′ commercial lengths
Trusted by dealers for high-volume versatility
| Specification | Detail |
|---|---|
| Model | C520 |
| MSRP | $7,214.20 |
| Frame | 6" Channel Frame & Tongue w/ Rub Rail |
| Hitch | 2 5/16 Ajustable Coupler BUMPER PULL |
| Axles | Axle, (2) 7K Electric, Spring (95-80) |
| Back | Straight Deck W/5' Slide In Ramps |
| Color | Midnight Black (DBS9-0UK12) |
| Tire | 235/80R16 LRE Radial 10ply Tires |
| Cross-member | Crossmembers, 3" Channel on 16" Centers |
| Fenders | Diamond Plate Fenders |
| Jack | Jack, (1) 12K Spring Loaded |
| Side | Stake Pockets & Rub Rail |
| Floor | Treated Pine Wood Floor |
