The F8 takes the full-width deckover concept and builds it on a heavy-duty 8-inch I-beam frame for significantly increased rigidity and load capacity. For operators who consistently haul near maximum capacity and need a frame that won’t flex over time.
Heavy-duty 8″ I-beam frame for maximum rigidity
Full 102″ deckover design — edge-to-edge surface
Six length configurations from 14′ to 24′
Reduced frame flex under maximum load conditions
| Specification | Detail |
|---|---|
| Model | F820 |
| MSRP | $10,133.20 |
| Frame | 8" x 13 lb I-Beam Frame & Tongue |
| Hitch | 2 5/16 Ajustable Coupler BUMPER PULL |
| Axles | Axle, (2) 7K Electric, Spring (81-64) |
| Back | Straight Deck with Slide-in Ramps |
| Color | Midnight Black (DBS9-0UK12) |
| Tire | 235/80R16 LRE Radial 10ply Tires |
| Cross-member | Crossmembers, 3" I-Beam on 16" Centers |
| Side | 6" Channel Outer Frame |
| Jack | Jack, (2) 12K Spring Loaded |
| Floor | Treated Pine Wood Floor |
| Spare Tire | No Spare Tire |
