The F3 pushes to 20,000 lb GVWR for operators moving heavier construction equipment, agricultural machinery, or oversized materials. Ten length options from 25 to 40 feet make this a top choice for contractors and equipment rental companies running high-utilization fleets.
20,000 lb GVWR for maximum single-axle capacity
102″ wide deck across 10 length configurations
Reinforced frame for consistent heavy-load performance
25′ to 40′ lengths for large equipment hauling
| Specification | Detail |
|---|---|
| Model | F330 |
| MSRP | $17,602.20 |
| Frame | 12" x 19 lb I-Beam Frame & Neck |
| Hitch | 2 5/16" 25K Round Gooseneck Coupler |
| Axles | Axle, (2) 10K Electric, Spring (85-64) |
| Back | Straight Deck with Slide-in Ramps |
| Color | Midnight Black (PBS9-00005) |
| Tire | 5 - 215/75R17.5 LRH Radial 16ply Tires |
| Cross-member | Crossmembers, 3" I-Beam on 16" Centers |
| Side | 6" Channel Outer Frame |
| Jack | Jack, (2) 12K Spring Loaded |
| Floor | Treated Pine Wood Floor |
| Low-Profile | Low-Pro Option |
