DD Series
Gooseneck 20K Tandem Dual Dump
The DD is built for the toughest hauling applications. With tandem dual axle capacity and a reinforced 12″ I-beam frame, it’s engineered for contractors who move serious material day in and day out without compromise.
Tandem dual axle design for maximum payload efficiency
12″ 19 lb I-beam frame and neck for extreme rigidity
Electric tarp kit standard for fast load coverage
8′ slide-in ramps for efficient loading access
STANDARD Specifications
| Specification | Detail |
|---|---|
| Model | DD20 |
| MSRP | $29,113.00 |
| Frame | 12" 19# IBeam Frame and Neck |
| Hitch | 2 5/16" 30K Gooseneck Coupler |
| Axles | Axle, (2) 10K Electric, Dual Tandem (74-47) |
| Back | 3-Way Spreader Gate W/ Slide-in Ramps |
| Color | Midnight Black (PBS9-00005) |
| Tire | 235/80R16 LRE Radial 10ply Tires |
| Spare Tire | Spare Tire Included |
| Jack | Jack, (1) 12K Spring Loaded |
| Side | 6' Solid Sides On Bin |
| Lift | 630 Hoist |
| Floor | 10GA Engineered Bed |
| Slide-in Rear Ramps | 8' Slide In Rear Ramps |
| Tarp Kit | Pull Back Tarp System |
| Cross-member | Crossmembers, 3" I-Beam on 12" Centers (per foot)***** |
| Wheel | Black Wheels |
