D3 — 14K Bumperpull Dump

MAXIMUM CAPACITY. BUMPER PULL CONVENIENCE.

D3 SERIES

14K BumperPull Dump

The D3 delivers serious payload capacity in a bumper pull configuration. Designed for demanding work environments, it provides the strength contractors need with the convenience of traditional towing — in three length configurations to match your volume.

ENGINEERING HIGHLIGHTS

Wide 83" bed for maximum material volume per load

Dual-axle configuration matched to workload demands

Heavy-duty I-beam frame engineered for high payloads

Reliable hydraulic dumping for tough, heavy materials

STANDARD Specifications

D314 Specifications
Specification Detail
Model D314
MSRP $12,660.20
Frame 8" x 13 lb I-Beam Frame & Tongue
Hitch 2 5/16 Ajustable Coupler BUMPER PULL
Axles Axle, (2) 7K Electric, Spring (95-80)
Back 3-Way Spreader Gate W/ Slide-in Ramps
Color Midnight Black (PBS9-00005)
Tire 235/80R16 LRE Radial 10ply Tires
Spare Tire No Spare Tire
Jack Jack, (1) 12K Spring Loaded
Side Solid Sides 2 FT
Lift 5" x 21.5" Cylinder Lift
Floor 10GA Engineered Bed
D-Ring 4 - D-Rings
Tarp Kit Pull Back Tarp System
Slide-in Rear Ramps 6' Slide-in Rear Ramps
Wheel Black Wheels
