FH | 20K-24K Low-Pro Dual Tandem Hydraulic Dove-Tail

HYDRAULIC DOVE. GROUND-LEVEL LOADING.

FD_Deckover_E_fhmnqh

Fh SERIES

20K-24K Low-Pro Dual Tandem Hydraulic Dove-Tail

Built for serious commercial hauling, the F5 raises the bar to 30,000 lb GVWR with a low-profile dual tandem configuration. Fifteen length options from 20 to 44 feet accommodate virtually any heavy equipment hauling scenario with reinforced structural steel throughout.

ENGINEERING HIGHLIGHTS

Hydraulic dovetail for smooth ground-level loading

Low-profile deck minimizes overall loading angle

Seven configurations from 28' to 40'

Eliminates wear associated with traditional mechanical dovetails

Flatbed Trailers

F1

14K Gooseneck Flatbed

F2

16K Gooseneck Flatbed (8K Axles)

F3

20K Gooseneck Flatbed

F5

30K Low-Pro Dual Tandem Flatbed

View all FLATBED Trailers →

Get Help

STANDARD Specifications

FH28 Specifications

Specification	Detail
Model	FH28
MSRP	$23,742.60
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH30 Specifications

Specification	Detail
Model	FH30
MSRP	$24,413.20
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH32 Specifications

Specification	Detail
Model	FH32
MSRP	$24,680.60
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH34 Specifications

Specification	Detail
Model	FH34
MSRP	$24,948.00
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH36 Specifications

Specification	Detail
Model	FH36
MSRP	$25,216.80
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH38 Specifications

Specification	Detail
Model	FH38
MSRP	$25,484.20
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame

FH40 Specifications

Specification	Detail
Model	FH40
MSRP	$25,751.60
Frame	12" x 19 lb I-Beam Frame & Neck
Hitch	2 5/16" 25K Round Gooseneck Coupler
Axles	Axle, (2) 10K Electric, Spring (74-47)
Back	Hydraulic Dove Tail
Color	Midnight Black (PBS9-00005)
Tire	235/80R16 LRE Radial 10ply Tires
Suspension	Standard Suspension
Cross-member	Crossmembers, 3" I-Beam on 16" Centers
Side	6" Channel Outer Frame
Jack	Jack, (2) 12K Spring Loaded
Floor	Treated Pine Wood Floor
Torque Tube	Torque Tube & Bridge Frame
